Below is a detailed introduction to its components and working principle:

I. Components

Forming System:Includes upper and lower molds and a pressure device. The molds are designed according to the product shape, and the pressure device uses vacuum adsorption, air pressure, or mechanical pressure to shape the softened plastic sheets into cups.

Cutting System:Employs punching molds or laser cutting equipment to separate the formed plastic cups from the sheet.

Control System:Equipped with a PLC controller and touchscreen interface to adjust parameters such as temperature, pressure, forming time, and cutting accuracy, enabling automated operation.

Scrap Recycling System:Collects and recycles cut scraps to reduce material waste.

Feeding and Heating:Plastic sheets are fed into the heating zone via the feeding system, where the heating system uniformly heats them to the softening temperature.

Cooling:The formed plastic cups are rapidly cooled and set within the mold using the cooling system.

Stacking and Collecting:The cut plastic cups are automatically stacked by the stacking system and collected at a designated location.

III. Workflow Diagram

The entire process is continuous and automated, ensuring high-efficiency production.

High Efficiency:High degree of automation and fast production speed, suitable for large-scale production.

Energy Saving and Environmental Protection:Utilizes energy-efficient heating systems and scrap recycling systems to reduce energy consumption and material waste.

V. Conclusion

Their automated design and precise control systems make them essential equipment in the plastic product manufacturing industry.
